Low pressure solar water heater with high efficiency vacuum tubes manufacturer from China Haining Hengji Solar water heater Technology Co., Ltd.

Low pressure solar water heater with high efficiency vacuum tubes

Price:	80.0~400.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean,Land

Packing: normal package

Installation: Wall Mounted

Certification: CE

Brand Name: ONTEK/OEM

Production Capacity: 5000sets/month

Delivery Date: 7 days after deposit

Type: Tank

Use: Bathroom

Capacity: 80-500L

Galvanized frame
55mm polyurethane foam
High efficiency vacuum tubes
5 years guarantee solar water heater

Good price non-pressure compact solar water heater with

high efficiency vacuum tubes solar water heater

1. Specification of our solar water heater

*Inner tank: SUS304-2B stainless steel, 0.4 mm thickness

*Outer tank: Color coated steel, 0.4mm thickness

*Insulation layer: polyurethan foam, 50mm thickness

*Frame: galvanized steel, 1.4mm thickness

*Vacuum tube: ALN/AIN-SS/CU, 58*1800mm, 1.6mm thickness

*Hail resistance: 25g with 1.6mm thickness

*Guarantee: 3 years guarantee for whole system, 15 years for vacuum tube

*Extra tube: 1% free spare tubes for replacement of full container

*Pressure: 0.05MPa=5Bar

* Capacity: 85-500 Liter

*OEM offered

2. Solar water heater description

Solar hot water systems supply an average 80-90% of a household annual water heating needs. With nearly 1/3 of the average electric or more than 1/2 of gas bill devoted to heating water, a solar hot water system is the best choice and smart investment you can make for your house and for the environment.

3. Loading information of integrated solar water heater

Type	Tube sizes	Tube QTY	Capacity	Loading Qty
Type	Tube sizes	Tube QTY	Capacity	20GP	40GP	40HQ
TJIP-B-15	Ø58X1800mm	15	150L	44	93	117
TJIP-B-18	Ø58X1800mm	18	180L	38	79	100
TJIP-B-20	Ø58X1800mm	20	200L	35	73	93
TJIP-B-25	Ø58X1800mm	25	250L	29	61	77
TJIP-B-30	Ø58X1800mm	30	300L	24	50	64
TJIP-B-36	Ø58X1800mm	36	360L	19	41	51
